Cardputer Adv

SKU: K132-Adv Category: IoT Devices Tag: Meshtastic
Brand: MTools Tec

$39.99

Cardputer-Adv: A compact, programmable card computer with ESP32-S3FN8, 1.14″ LCD, 56-key keyboard, audio I/O, sensors, and LEGO-compatible design. Ideal for engineers in testing, industrial, and home control.

Secure Checkout

Fast Shipping

Easy Returns

24/7 Support

Product Features

Stamp-S3A Core Controller
56-key keyboard
1.14″ LCD screen
160gf comfortable key feel
ES8311 audio decoding chip
High-noise-level MEMS microphone
NS4150B amplifier chip and 1W speaker
3.5mm audio output interface
Infrared emitter tube
6-axis posture sensor BMI270
HY2.0-4P Grove interface
EXT 2.54-14P expansion bus
MicroSD card slot
Built-in 1750mAh lithium battery
Back magnetic adsorption design
Compatible with Lego port
Development platform
Arduino
UiFlow2
ESP-IDF

Package Include

1 x Cardputer-Adv

Applications

Rapid Functionality Validation and Prototype Design
Industrial Control and Automation
Embedded Systems Development and Learning
Wireless Communication and IoT (IoT) Projects

How to Enter Download Mode?

Turn off the Cardputer-Adv side feature in the download mode, then press G0 at startup, then release it after the device powers on, and the device will enter download mode.

Speaker Functions

When inserting the 3.5mm earphone socket into the headphone, the headphone amplifier shuts down.

Pin Out

FUNC	PIN	LEFT	RIGHT	PIN	FUNC
RESET	G3	1	2	5VIN
INT	G4	3	4	GND
BUSY	G6	5	6	5VOUT
SCK	G40	7	8	G8	I2C_SDA
MOSI	G14	9	10	G9	I2C_SCL
MISO	G39	11	12	G13	UART_RX
CS	G5	13	14	G15	UART_TX
