M5StickC PLUS ESP32-PICO Mini IoT Development Kit
M5StickC PLUS ESP32-PICO Mini IoT Development Kit - Image 2
M5StickC PLUS ESP32-PICO Mini IoT Development Kit - Image 3
M5StickC PLUS ESP32-PICO Mini IoT Development Kit - Image 4
M5StickC PLUS ESP32-PICO Mini IoT Development Kit - Image 5
M5StickC PLUS ESP32-PICO Mini IoT Development Kit - Image 6

M5StickC PLUS ESP32-PICO Mini IoT Development Kit

Original price was: $29.99.Current price is: $23.99.

Out of stock

Miniaturized IoT development kit featuring ESP32-PICO module, Wi-Fi, Bluetooth, and rich peripherals, ideal for prototyping and developing IoT projects.

  • ESP32-based support Wi-Fi
  • Built-in 6-Axis IMU
  • Red LED
  • IR transmitter
  • Microphone
  • RTC
  • Buttons, LCD(1.14 inch)
  • Built-in Lithium Polymer Battery
  • Extendable Socket
  • Built-in Passive Buzzer
  • Wearable & Wall mounted
  • Compatible with multi-platform development:

Frequently Bought Together

All-In-One PN532
Quick View

All-In-One PN532

$19.99 – $49.99
M5Stack Cardputer
Quick View

M5Stack Cardputer

$39.99 – $69.99

M5StickC PLUS is an upgraded version of the original M5StickC, featuring ESP32-PICO-D4 with Wi-Fi connectivity and a larger screen. This compact and portable IoT development board is designed to be user-friendly and open source, allowing you to easily bring your ideas to life and accelerate your IoT prototyping process. With M5StickC PLUS, you can enjoy a streamlined development experience, reducing the complexities often associated with building IoT projects.

As one of the core devices in the M5Stack product series, M5StickC PLUS offers a rich set of hardware resources integrated into its compact body. These resources include infrared, RTC, microphone, LED, IMU, buttons, and PMU. Notably, this upgraded version introduces new features such as a buzzer, a larger 1.14-inch LCD screen with a resolution of 135 * 240, and a more stable hardware design. The increased display area by 18.7% and the enhanced battery capacity from 95mAh to 120mAh further enhance the usability and performance of the device.

M5StickC PLUS is designed to support the HAT and Unit family of products, expanding its capabilities and providing compatibility with various accessories and modules. This allows you to easily extend the functionality of your projects and explore a wide range of possibilities. With its improved features and expanded compatibility, M5StickC PLUS is an excellent choice for IoT development, enabling you to create innovative solutions with ease.

Power switch operation:

  • Power on :Press power button for 2 seconds
  • Power off :Press power button for 6 seconds

Include

  • 1x M5StickC Plus

Applications

  • Internet of things terminal controller
  • Wearable devices
  • Stem education product
  • DIY creation
  • IoT development kit

Specification

Resources Parameter
ESP32 240MHz dual core, 600 DMIPS, 520KB SRAM, Wi-Fi
Flash Memory 4MB
Power Input 5V @ 500mA
Port TypeC x 1, GROVE(I2C+I/0+UART) x 1
LCD screen 1.14 inch, 135*240 Colorful TFT LCD, ST7789v2
Button Custom button x 2
LED RED LED
MEMS MPU6886
Buzzer built-in buzzer
IR Infrared transmission
MIC SPM1423
RTC BM8563
PMU AXP192
Battery 120 mAh @ 3.7V
Antenna 2.4G 3D Antenna
PIN port G0, G25/G36, G26, G32, G33
Operating Temperature 0??C to 60??C
Net weight 15g
Gross weight 21g
Product Size 48.2*25.5*13.7mm
Package Size 65*25*15mm
Case Material Plastic ( PC )
